Posted on 04/25/2023 1:19:38 PM PDT by Red Badger
Scientists at ETH Zurich have made progress in creating heavier Schrödinger cats, which can be alive (top) and dead (bottom) at the same time. Credit: Yiwen Chu / ETH Zurich
Researchers at ETH Zurich have created the heaviest Schrödinger cat to date by putting a crystal in a superposition of two oscillation states. Their results could lead to more robust quantum bits and help to explain why quantum superpositions are not observed in everyday life.
Researchers at ETH Zurich have created the heaviest Schrödinger cat to date. For this, they combined an oscillating crystal with a superconducting circuit. They hope to better understand the reason behind the disappearance of quantum effects in the macroscopic world.
Even if you are not a quantum physicist, you will most likely have heard of Schrödinger’s famous cat. Erwin Schrödinger came up with the feline that can be alive and dead at the same time in a thought experiment in 1935. The obvious contradiction – after all, in everyday life we only ever see cats that are either alive or dead – has prompted scientists to try to realize analogous situations in the laboratory. So far, they have managed to do so using, for instance, atoms or molecules in quantum mechanical superposition states of being in two places at the same time.
At ETH, a team of researchers led by Yiwen Chu, professor at the Laboratory for Solid State Physics, has now created a substantially heavier Schrödinger cat by putting a small crystal into a superposition of two oscillation states. Their results, which have been published this week in the scientific journal Science, could lead to more robust quantum bits and shed light on the mystery of why quantum superpositions are not observed in the macroscopic world.
Cat in a box
In Schrödinger’s original thought experiment, a cat is locked up inside a metal box together with a radioactive substance, a Geiger counter and a flask of poison. In a certain time-frame – an hour, say – an atom in the substance may or may not decay through a quantum mechanical process with a certain probability, and the decay products might cause the Geiger counter to go off and trigger a mechanism that smashes the flask containing the poison, which would eventually kill the cat. Since an outside observer cannot know whether an atom has actually decayed, he or she also doesn’t know whether the cat is alive or dead – according to quantum mechanics, which governs the decay of the atom, it should be in an alive/dead superposition state. (Schrödinger’s idea is commemorated by a life-size cat figure outside his former home at Huttenstrasse 9 in Zurich).
Heavier Schrödinger Cats
In the ETH Zurich experiment, the cat is represented by oscillations in a crystal (top and blow-up on the left), whereas the decaying atom is emulated by a superconducting circuit (bottom) coupled to the crystal. Credit: Yiwen Chu / ETH Zurich
“Of course, in the lab we can’t realize such an experiment with an actual cat weighing several kilograms,” says Chu. Instead, she and her co-workers managed to create a so-called cat state using an oscillating crystal, which represents the cat, with a superconducting circuit representing the original atom. That circuit is essentially a quantum bit or qubit that can take on the logical states “0” or “1” or a superposition of both states, “0+1”. The link between the qubit and the crystal “cat” is not a Geiger counter and poison, but rather a layer of piezoelectric material that creates an electric field when the crystal changes shape while oscillating. That electric field can be coupled to the electric field of the qubit, and hence the superposition state of the qubit can be transferred to the crystal.
Simultaneous oscillations in opposite directions
As a result, the crystal can now oscillate in two directions at the same time – up/down and down/up, for instance. Those two directions represent the “alive” or “dead” states of the cat. “By putting the two oscillation states of the crystal in a superposition, we have effectively created a Schrödinger cat weighing 16 micrograms,” explains Chu. That is roughly the mass of a fine grain of sand and nowhere near that of a cat, but still several billion times heavier than an atom or molecule, making it the fattest quantum cat to date.
In order for the oscillation states to be true cat states, it is important that they be macroscopically distinguishable. This means that the separation of the “up” and “down” states should be larger than any thermal or quantum fluctuations of the positions of the atoms inside the crystal. Chu and her colleagues checked this by measuring the spatial separation of the two states using the superconducting qubit. Even though the measured separation was only a billionth of a billionth of a meter – smaller than an atom, in fact – it was large enough to clearly distinguish the states.
Measuring small disturbances with cat states
In the future, Chu would like to push the mass limits of her crystal cats even further. “This is interesting because it will allow us to better understand the reason behind the disappearance of quantum effects in the macroscopic world of real cats,” she says. Beyond this rather academic interest, there are also potential applications in quantum technologies. For instance, quantum information stored in qubits could be made more robust by using cat states made up of a huge number of atoms in a crystal rather than relying on single atoms or ions, as is currently done. Also, the extreme sensitivity of massive objects in superposition states to external noise could be exploited for precise measurements of tiny disturbances such as gravitational waves or for detecting dark matter.
Reference: “Schrödinger cat states of a 16-microgram mechanical oscillator” by Marius Bild, Matteo Fadel, Yu Yang, Uwe von Lüpke, Phillip Martin, Alessandro Bruno and Yiwen Chu, 20 April 2023, Science.
DOI: 10.1126/science.adf7553
https://www.youtube.com/watch?v=hB7rgJAGoE0
No propellant. If this works, it will have a massive impact on the world of physics.
PETA needs to take legal action against these researchers...
very cool, now how does it work...
not even a hint
Why can’t cats just play Russian Roulette if they are into these deadly games?
” Yiwen Chu”
Why is it disconcerting to me that so many Chinese names are behind these new discoveries and experiments???
Could it be the white western world is so focused on “woke” bull crap that the Chinese are studying hard sciences for the advancement of the CCP rather then learning how global warming effects transgendered people of color and their poetry?
We may find out in June. Maybe even later. I assume it will have a very small thrust, and so it may take some time to see if it's even moving to any appreciable degree.
not even a hint
I believe there is a hint. It's in the name "quantum" drive.
Some years back, there was a proposal to utilize the effect of virtual particles spontaneously popping into existence to act as propellant. When a particle popped into existence, it would be accelerated by an electric field before it disappeared again, thereby imparting a reaction force to the "engine."
virtual particles spontaneously popping into existence
that’d do it...
I thought the point was that any measuring device alters the observation. If you try to get a good fix on the position of the particle, you can’t get a good fix on the velocity, and vice versa.
Aunt Bethany's cat started out in a box and we all know what happened to it.
(see 'Hellsing Ultimate' for more information.)
Interesting... thanks for the link.
quantum propulsion system?
Beam me up!.......................
Yes.......................
True.
You can know the position or the velocity but not both...................................
Right — so no matter how the observation is made, it alters the state of the cat.
